Description
Technical Parameters
★Overall Dimension(Customizable):L1400xW335xH980mm.
★Material:Austenitic stainless steel 304.
★Power supply voltage: AC220V+10V; and
★Drive motor: Brushless motor 24~36VDC
★Service life: more than 5 million times of continuous opening and closing.
★Infrared sensor: 6 pairs; (support more than 6 pairs of configuration)
★Operating ambient temperature:-35℃ ~ +75℃.
★Relative humidity: 0~90% (no condensation); (support more than 6 pairs of configuration)
★Communication interface: RS232 serial port.
★Communication protocol: MODBUS protocol
★Maximum channel width:550~600MM.
★Passing speed:≤30 persons/minute.
★Box structure: frame structure/standard stainless steel shell.
★Movement structure: full-height direct-drive movement, upper and lower screws, solid force; high-precision movement and motor direct -drive, higher precision, faster switching speed, longer service life (patented products)
★Application Scenario: Suitable for indoor/outdoor pedestrian passage places; such as: scenic spots/parks/playgrounds/primary and secondary schools/higher education institutions/offices/hotels/residential districts/factory parks/hospitals/enterprise and public affairs halls/sports venues and other scenarios
